Product Description
When you load up your John Deere Gator with those heavy loads Side By Side Stuff knows that your UTV can get stuck in the mud, snow or slush. What you need is the Camso UTV 4S1 Track System for your Gator XUV 550, 560, 590. The track system will let you tackle all those tough terrains and handle nearly anything that gets in your way. Speaking of heavy loads, when your carrying heavy items and encounter rocks, your air filled tire can get punctured. With tracks, never worry about getting a flat tire miles from home.
These tracks have a larger, wider wheelbase, allowing you to drive over mud and snow instead of sinking like regular tires would. When it comes to rocky terrain or uneven terrain, the full track system can handle that too. The tracks have a larger surface area, allowing them to find and grip rocks, uneven terrain and slick areas better than a tire can. While your ground clearance will become larger, the low center of gravity will prevent your Gator from tipping over easier. The tracks will absorb more of the bumps and vibrations than tires will, making for smoother ride.
Camso 4S1 tracks are specifically designed to utilize and maximize the available horsepower and torque from your machine. Check out some of the features listed below and the brochure for further information to see if this track system is a must have for your Gator.
These tracks have a larger, wider wheelbase, allowing you to drive over mud and snow instead of sinking like regular tires would. When it comes to rocky terrain or uneven terrain, the full track system can handle that too. The tracks have a larger surface area, allowing them to find and grip rocks, uneven terrain and slick areas better than a tire can. While your ground clearance will become larger, the low center of gravity will prevent your Gator from tipping over easier. The tracks will absorb more of the bumps and vibrations than tires will, making for smoother ride.
Camso 4S1 tracks are specifically designed to utilize and maximize the available horsepower and torque from your machine. Check out some of the features listed below and the brochure for further information to see if this track system is a must have for your Gator.
- Fitment
- Features
- Videos
- Important Info
- Reviews
- Contact an Expert
Fitment
- 2024 John Deere Gator XUV590M -
- 2024 John Deere Gator XUV590M S4 -
- 2024 John Deere Gator XUV560E -
- 2024 John Deere Gator XUV560E S4 -
- 2023 John Deere Gator XUV 590M -
- 2023 John Deere Gator XUV 590M S4 -
- 2023 John Deere Gator XUV 590E -
- 2023 John Deere Gator XUV 560E -
- 2023 John Deere Gator XUV 560E S4 -
- 2022 John Deere Gator XUV 590M -
- 2022 John Deere Gator XUV 590M S4 -
- 2022 John Deere Gator XUV 590E -
- 2022 John Deere Gator XUV 590E S4 -
- 2022 John Deere Gator XUV 560E -
- 2022 John Deere Gator XUV 560E S4 -
- 2021 John Deere Gator XUV 590M -
- 2021 John Deere Gator XUV 590M S4 -
- 2021 John Deere Gator XUV 590E -
- 2021 John Deere Gator XUV 590E S4 -
- 2021 John Deere Gator XUV 560E -
- 2021 John Deere Gator XUV 560E S4 -
- 2020 John Deere Gator XUV 590M -
- 2020 John Deere Gator XUV 590M S4 -
- 2020 John Deere Gator XUV 590E -
- 2020 John Deere Gator XUV 590E S4 -
- 2020 John Deere Gator XUV 560E -
- 2020 John Deere Gator XUV 560E S4 -
- 2019 John Deere Gator XUV 590M SE
- 2019 John Deere Gator XUV 590M -
- 2019 John Deere Gator XUV 590M S4 -
- 2019 John Deere Gator XUV 590E -
- 2019 John Deere Gator XUV 590E S4 -
- 2019 John Deere Gator XUV 560E -
- 2019 John Deere Gator XUV 560E S4 -
- 2018 John Deere Gator XUV 590M -
- 2018 John Deere Gator XUV 590M S4 -
- 2018 John Deere Gator XUV 590E -
- 2018 John Deere Gator XUV 590E S4 -
- 2018 John Deere Gator XUV 560 -
- 2018 John Deere Gator XUV 560 S4 -
- 2017 John Deere Gator XUV 590i Power Steering
- 2017 John Deere Gator XUV 590i -
- 2017 John Deere Gator XUV 590i S4 Power Steering
- 2017 John Deere Gator XUV 590i S4 -
- 2017 John Deere Gator XUV 560 -
- 2017 John Deere Gator XUV 560 S4 -
- 2016 John Deere Gator XUV 590i Power Steering
- 2016 John Deere Gator XUV 590i -
- 2016 John Deere Gator XUV 590i S4 Power Steering
- 2016 John Deere Gator XUV 590i S4 -
- 2016 John Deere Gator XUV 560 -
- 2016 John Deere Gator XUV 560 S4 -
- 2016 John Deere Gator XUV 550 -
- 2016 John Deere Gator XUV 550 S4 -
- 2015 John Deere Gator XUV 550 -
- 2015 John Deere Gator XUV 550 S4 -
- 2014 John Deere Gator XUV 550 -
- 2014 John Deere Gator XUV 550 S4 -
- 2013 John Deere Gator XUV 550 -
- 2013 John Deere Gator XUV 550 S4 -
- 2012 John Deere Gator XUV 550 -
- 2012 John Deere Gator XUV 550 S4 -
Features
- Ground coverage: Approximately 2520 sq. in.
- Average ground clearance: Increased by 5 in vs tires
- Climb 20 degree hills
- Tested in deep snow
- Haul up to 1000 lb of supplies
- Tow your 2500 lb shack at speed up to 25 km/h across ice and snow
- Foam tires with adjusted shape on idler wheels cushions the ride
- Rubber mounted shafts on tandem stabilizer and wheels absorbs shocks for a more stable ride
- Flex-Track design offers smoother rides than a flat track
- Large contact patch eliminates rebounding and improves vehicle lateral stability when sidehilling
- 1.125-inch lug height enhances traction and control by reducing track ratio
- Solid steel frame sheds snow, mud and debris
- High density tires adjusted shape reduces friction and wear
- Wheel seal design reduces wear and prevents water absorption
- Triple hub bearing design oil bath lubrication and stainless sleeves increase lifespan and reduce maintenance
- Adapted sprocket size optimizes gear ratio for more efficient power transfer
- Front mounted tracks with Flex-Track technology with slight inward curve offers more stable handling
- System design optimizes steering stability to reduce effort
- 2 year limited warranty that covers manufacturing defects related to materials and workmanship
Technical Specs:
- Drive type: Internal drive
- Sprocket: 15 to 18 teeth
- Frame: Carbon steel
- Redesigned mild steel anti-rotation single rate spring and progressive damper
- Quick connect steering limiter design
- Weight: Front - 103 lbs; Rear - 120 lbs
- Oiled 3-bearing with forged steel multi-bolt (4-5) pattern hub
- 5.2 in double-bearing mid-roller wheels (1.97 in width)
- 9.49 in double-bearing flat-free tires
- Bladder type wheel cap and face seal
- Rubber Track Design: Front - Flex; Rear - Flat
- Track length: Front - 98.5 in; Rear - 116.7 in
- Track lug height: 1.125 in
- Track width: Front - 12.5 in; Rear - 14 in
Overall Dimensions:
- System length: F: 42.5 in; R: 52 in
- Offset length: F: 26.5 in; R: 35 in
- System width: F: 12.5 in; R: 14 in
- Offset width: 7.25 in
- Ground clearance: F: 16 3/8 in; R: 16 1/2 in
- System height: F: 25 in; R: 24.7 in
Videos
Important Info
- Shared Shipping Program: You pay You pay $450.00 shipping/handling and Side By Side Stuff will pay the rest!
- These track systems can only be shipped to a business / commercial address. It will not ship to a residential address.
- This product is only offered to buyers in the U.S.
- Minor modification and light interference are possible on any model.
- These tracks have permanent interference.
- Designed to work with factory suspension.
