Yamaha Wolverine X4S Track System

Camso UTV X4S Track System - Yamaha Wolverine
Camso UTV X4S Track System - Yamaha Wolverine - alt image 0
Camso UTV X4S Track System - Yamaha Wolverine - alt image 1
Camso UTV X4S Track System - Yamaha Wolverine - alt image 2
Camso UTV X4S Track System - Yamaha Wolverine
Camso UTV X4S Track System - Yamaha Wolverine
Camso UTV X4S Track System - Yamaha Wolverine
Camso UTV X4S Track System - Yamaha Wolverine

Yamaha Wolverine X4S Track System

Ships within 2-3 business days *SHARED SHIPPING*
Located outside the US? Call us for a shipping quote.
Item #: 82-10386
Mfg Part #: 7522-07-1638
Brand: Camso
$5,049.00
Quantity:
Eligible for ?

SSL Secure and
Privacy Guaranteed

  • SSL Secured

  • Rating

  • Expert Support

Product Description

Where you live can determine the way you ride, and sometimes trekking anywhere is out of the question. Especially for those of you who live where things get super wet or extra snowy. Thanks to Camso, over-the-top environments can still be handled, you just need the right kind of traction. Like with the Yamaha Wolverine X4S UTV Track System available at Side By Side Stuff.

The aftermarket accessory allows all-travel in nearly any conditions Mother Nature can cook up. Using advanced technology called Flextrack, Camso has improved handling and shock absorption while reducing vibration and splatter issues. Its floatation abilities make it virtually impossible to get stuck! So what are you waiting for; take control of your situation by swapping out your SxS wheels and tires for a Wolverine track system.
  • Fitment
  • Features
  • Videos
  • Important Info
  • Reviews
  • Contact an Expert

Fitment

  • 2018 Yamaha Wolverine R-Spec EPS SE
  • 2018 Yamaha Wolverine R-Spec EPS
  • 2018 Yamaha Wolverine R-Spec
  • 2018 Yamaha Wolverine -
  • 2017 Yamaha Wolverine R-Spec EPS SE
  • 2017 Yamaha Wolverine R-Spec EPS
  • 2017 Yamaha Wolverine R-Spec
  • 2017 Yamaha Wolverine EPS
  • 2017 Yamaha Wolverine -
  • 2016 Yamaha Wolverine R-Spec EPS SE
  • 2016 Yamaha Wolverine R-Spec EPS
  • 2016 Yamaha Wolverine R-Spec
  • 2016 Yamaha Wolverine -

Features

  • Ground coverage: Approximately 2000 sq. in
  • Average ground clearance: Increased by 3 in vs tires
  • Front mounted tracks with Flex-Track sides and slight inward curve offers more stable handling
  • Geometry of solid steel frame enhances front steering & handling
  • Large contact patch eliminates rebounding and improves vehicle power and lateral stability when sidehilling
  • 1.125-inch lug height enhances traction and control by reducing track ratio
  • Solid steel frame sheds snow, mud and debris
  • Double bearing hubs and oil bath housing optimizes durability
  • Double bearing bolted on mid-roller and idler wheels improves performance and simplifies maintenance
  • Adapted sprocket size optimizes gear ratio for better power transfer
  • Flex-Track design provides a smoother ride than flat tracks
  • Cone dampers reduce vibrations on the tandem and rear tracks
  • 2-year limited warranty covers manufacturing defects related to materials and workmanship

Technical Specs:
  • Drive type: Internal drive
  • Sprocket: 15 to 18 teeth
  • Frame: Carbon steel
  • Redesigned mild steel anti-rotation single rate spring and progressive damper
  • Quick connect steering limiter design
  • Weight: Front - 72.6 lbs; Rear - 79.4 lbs
  • Cast steel multi-bolt (4) pattern
  • 5.3 and 7.9 in double bearing wheels
  • Standard and replaceable sealed bearings
  • Elastomer outer band
  • Bladder type wheel cap
  • Rubber Track Design: Front - Flex; Rear - Flat
  • Track length: Front - 93.4 in; Rear - 98.5
  • Track lug height: Front - 1.125 in; Rear - 1.25
  • Track width: Front - 11.5 in; Rear - 12.5 in

Overall Dimensions:
  • System length: F: 40 in; R: 42.5 in
  • Offset length: F: 24 in; R: 27 in
  • System width: F: 11.5 in; R: 12.5 in
  • Offset width: 6 in
  • Ground clearance: F: 15 3/8 in; R: 14 5/8 in
  • System height: F: 23.8 in; R: 23.2 in



Videos

Important Info

  • Shared Shipping Program: You pay You pay $450.00 shipping/handling and Side By Side Stuff will pay the rest!
  • These track systems can only be shipped to a business / commercial address. It will not ship to a residential address.
  • This product is only offered to buyers in the U.S.
  • Minor modification and light interference are possible on any model.
  • These tracks cause permanent interference.
  • A suspension lift kit is required.
  • Designed to work with factory suspension.
