Honda Pioneer 500, 520 4S1 Track System
Honda Pioneer 500, 520 4S1 Track System
SSL Secured
Expert Support
Product Description
Ready to unlock the true all terrain potential of your Honda Pioneer 500 or 520? The Camso UTV 4S1 Track System is the ultimate upgrade, transforming your sxs into an unstoppable, all season beast! Engineered for those who demand uncompromising performance, flotation, and durability, the 4S1 system will take you to places tires simply can't reach, from deep snow and muddy swamps to rugged ice and marshlands.
Features That Set the Standard:
Why You Need the UTV 4S1:
It's time to put your Honda Pioneer 500 or 520 in 'Beast Mode' and conquer the extremes!
Buy Your Camso UTV 4S1 Track System at Side By Side Stuff Today! We offer a wide selection of top quality UTV parts and accessories, ensuring you get the perfect fit for your machine. Don't let your season end, upgrade your SxS today and experience the difference!
Features That Set the Standard:
- Exclusive Flextrack Technology: The front tracks feature flexible sides and a slight inward curve, offering superior shock absorption and reduced vibration. Enjoy a more comfortable ride than traditional flat tracks and get more precise steering, perfect for long days on the trails or tough work hours.
- Unmatched Durability: Built for the long haul, the system features a Solid Steel Frame that is open and lightweight, easily shedding snow, mud, and debris. Triple Hub Bearings with oil bath lubrication and stainless sleeves increase lifespan and reduce maintenance.
- Superior Traction and Flotation: The large contact patch and 1.125-inch lug height eliminate rebounding, significantly improve lateral stability when sidehilling, and enhance traction and control in the slickest conditions. Increase your ground clearance and float effortlessly over deep snow and soft terrain.
- Smooth, Stable Ride: Rubber-Mounted Shafts on the tandem stabilizers absorb shocks for a smoother, more stable ride, even over obstacles like rocks and downed trees.
- Optimized Performance: Sprocket size is adapted to optimize the gear ratio, ensuring efficient power transfer and utilizing the available horsepower and torque of your Honda Pioneer 500 or 520.
Why You Need the UTV 4S1:
- Go Anywhere, Anytime. Stop letting the weather or terrain limit your adventures or your work. Whether it's winter hauling, hunting, or navigating a soggy trail, this track system gives you snowmobile-like capability in a UTV.
- Work Harder, Ride Easier. The enhanced weight distribution, greater stability, and massive increase in traction mean you can haul heavier loads and tackle steep inclines (up to 20 degrees in deep snow) with confidence and less effort.
- Invest in Reliability. The tough, maintenance-friendly design features like puncture-proof tires and enhanced wheel seals mean less time in the garage and more time exploring.
It's time to put your Honda Pioneer 500 or 520 in 'Beast Mode' and conquer the extremes!
Buy Your Camso UTV 4S1 Track System at Side By Side Stuff Today! We offer a wide selection of top quality UTV parts and accessories, ensuring you get the perfect fit for your machine. Don't let your season end, upgrade your SxS today and experience the difference!
- Fitment
- Features
- Videos
- Important Info
- Reviews
- Contact an Expert
Fitment
- 2025 Honda Pioneer 520 -
- 2023 Honda Pioneer 520 -
- 2023 Honda Pioneer 500 -
- 2022 Honda Pioneer 520 -
- 2022 Honda Pioneer 500 -
- 2021 Honda Pioneer 520 -
- 2021 Honda Pioneer 500 -
- 2020 Honda Pioneer 500 -
- 2019 Honda Pioneer 500 -
- 2018 Honda Pioneer 500 -
- 2017 Honda Pioneer 500 -
- 2016 Honda Pioneer 500 -
- 2015 Honda Pioneer 500 -
Features
- Ground coverage: Approximately 2520 sq. in.
- Average ground clearance: Increased by 5 in vs tires
- Climb 20 degree hills
- Tested in deep snow
- Haul up to 1000 lb of supplies
- Tow your 2500 lb shack at speed up to 25 km/h across ice and snow
- Foam tires with adjusted shape on idler wheels cushions the ride
- Rubber mounted shafts on tandem stabilizer and wheels absorbs shocks for a more stable ride
- Flex-Track design offers smoother rides than a flat track
- Large contact patch eliminates rebounding and improves vehicle lateral stability when sidehilling
- 1.125-inch lug height enhances traction and control by reducing track ratio
- Solid steel frame sheds snow, mud and debris
- High density tires adjusted shape reduces friction and wear
- Wheel seal design reduces wear and prevents water absorption
- Triple hub bearing design oil bath lubrication and stainless sleeves increase lifespan and reduce maintenance
- Adapted sprocket size optimizes gear ratio for more efficient power transfer
- Front mounted tracks with Flex-Track technology with slight inward curve offers more stable handling
- System design optimizes steering stability to reduce effort
- 2 year limited warranty that covers manufacturing defects related to materials and workmanship
Technical Specs:
- Drive type: Internal drive
- Sprocket: 15 to 18 teeth
- Frame: Carbon steel
- Redesigned mild steel anti-rotation single rate spring and progressive damper
- Quick connect steering limiter design
- Weight: Front - 103 lbs; Rear - 120 lbs
- Oiled 3-bearing with forged steel multi-bolt (4-5) pattern hub
- 5.2 in double-bearing mid-roller wheels (1.97 in width)
- 9.49 in double-bearing flat-free tires
- Bladder type wheel cap and face seal
- Rubber Track Design: Front - Flex; Rear - Flat
- Track length: Front - 98.5 in; Rear - 116.7 in
- Track lug height: 1.125 in
- Track width: Front - 12.5 in; Rear - 14 in
Overall Dimensions:
- System length: F: 42.5 in; R: 52 in
- Offset length: F: 26.5 in; R: 35 in
- System width: F: 12.5 in; R: 14 in
- Offset width: 7.25 in
- Ground clearance: F: 16 3/8 in; R: 16 1/2 in
- System height: F: 25 in; R: 24.7 in
Videos
Important Info
- Shared Shipping Program: You pay You pay $450.00 shipping/handling and Side By Side Stuff will pay the rest!
- These track systems can only be shipped to a business / commercial address. It will not ship to a residential address.
- This product is only offered to buyers in the U.S.
- Minor modification and light interference are possible on any model.
- These tracks have permanent interference.
- Designed to work with factory suspension.
